alo yoga public passenger lift

project showcase

Stainless steel elevator doors in Alo Yoga store with black and white clothes on the rack nearby.

alo yoga - passenger lift dda

Location: Regent Street, London
Status: Completed
Lift Type: ‍Passenger Lift
Design and installation of a DDA-compliant passenger lift in central London at Alo Yoga’s flagship Regent Street store, including a 2-stop, 630kg capacity system with low-pit solution for improved accessibility.
Technical floor plan of an elevator shaft showing dimensions, cabinet locations, and safety zones.
2
STOPS
3790 MM
TRAVEL
1 M/S
SPEED
630 KG
RATED LOAD
Bright modern clothing store interior with racks of apparel, mannequins, and decorative plants.

low pit design (500mm from ffl)

Due to the depth of the existing concrete footings, further excavation would have compromised the building structure. To address this, we engineered a space-efficient solution compliant with EN81-20 and EN81-21 standards, with an initial pit depth of just 320mm from FFL, later increased to 500mm.
Technical drawing of elevator maintenance and lowest positions with dimensions and a safety sign.Elevator machinery with yellow support frame and steel cables inside a brick shaft.Interior of a passenger lift shaft showing cables, control panel, and brick walls in Alo Yoga, London.Open public passenger elevator beside two people shopping for clothes in a modern retail store.Closed stainless steel elevator doors inside a modern store with directional signs for women and men.Open public passenger lift in a modern store with clothing racks and signs for fitting rooms and shoes.Open empty modern passenger lift in Alo Yoga store with reflective mirrored wall and lighted edges on floor.
